High Biocompatibility:

• Rapid recovery and healing of tissues without causing inflammation
• Releases Calcium Ions – Calcium Hydroxide and Calcium Silicate Hydrate
• High pH for antibacterial action (pH 12)
• Induces hard tissue regeneration in sites with bone lesion and microbial activity

Perfect Seal:

• Perfect sealing ability for multiple and lateral root canals
• Superior adhesion between gutta percha points and dentin
• Long-term stability with no shrinkage/expansion

Low Solubility:

• Low solubility (0.95%) to maintain an excellent sealing ability inside the root canals
• Washout resistant: prevents micro leakage

Optimal Flowability:

• Flow rate of 22mm: Complete apical seal
• High flow rate and low film thickness ensure easy penetration into lateral and accessory canals

Pre-Mixed, Pre-Filled Syringe:

• Ready to use formula for an easy, convenient, and fast application

Adequate Working/Setting Time:

• 6 hours: adequate time to be used by specialist and general practitioners

Easy to Store:

• Can be stored and used over 6 months after opening
• Does not harden easily: Reduce waste of materials to a minimum

Excellent Radiopacity:

• 8.1mm Al­­

1. Prepare the root canal cleand, and dried.
2. Fill the root canal slowly with DIA-ROOT BIO SEALER to the coronal third of the canal.
3. Insert the selected gutta percha cone and lightly pump the gp cone up and down the root canal to fill up the apex.
4. Cut the master cone at the desired level with DUO-PEN/heating source and remove the excess sealer from the root canal.
5. Complete root canal treatment.

1. Prepare the root canal cleand, and dried.
2. Fill the root canal slowly with DIA-ROOT BIO SEALER to the coronal third of the canal.
3. Insert the selected gutta percha cone and lightly pump the gp cone up and down the root canal to fill up the apex.
4. Cut the master cone at the desired level with DUO-PEN.
5. Condense the gutta percha cone with DUO-PEN and extrude melted gutta percha and fill the canal with DUO-GUN.
6. Complete root canal treatment.
